Multi Wire saw machine

• Place of Origin:

   India

• Type:

  Sawing and Cutting Machinery

• Genre:

  Machinery & Equipment

• sCode:

  STPR1469220

• Place of Origin:

  China
• Technical Specification of Multi Wire Saw Machine for 30 wire.
  · Maximum Block Size :L 3650mm x B 2000mm x H 2300mm
  · Slab Thickness :20mm
  · Post Height (Fabricated) :5mtr. (4695m
  · Vertical Slide (Fabricated) :2mtr.(2000mm)
  · Aluminum Fly wheel with Rubber Ring having Size and Pcs. :600mm dia x 150pcs.
  · Manual Operation to Adjust Distance Between Fly wheels :20mm and 30mm
  · Guide wheels size and Nos. :300mm dia x 90pcs.
  · Trolley size (50ton Capacity) :4mtr x 2.5mtr (4000mm x 2440mm)
  · Rail Track (60pound) :20ft.
  · Applicable Rubber Coated Wire Saw for Granite (8mm dia.) :21mtr. (40pcs/mtr.)
  · Wire Speed (Variable) :22mtr-30mtr/sec.
  · Wire Cutting Rate :20-30cm/hr.
  · Wire Tension :250kg/one side
  · Water Consumption :15 lt/min./wire
  · Main AC Electric Motor :60HP /variable speed
  · Gear Box With AC Electric Motor for up & down moment :3 HP with AC Drive
  · Gear Box with AC Electric Motor for Trolley moment :3 HP with AC Drive
  · Electric Penal 60HP / PLC Controls with screen. :90 Amps. Input
  · Sensors ( to control down feed and wire breakages.)
