CNC waterjet cutting machine

• Place of Origin:

   China

• Type:

  Sawing and Cutting Machinery

• Genre:

  Machinery & Equipment

• sCode:

  STPR1467071

• Place of Origin:

  China
• CNC waterjet cutting machines

  Extra-high pressure generators of B2B380 waterjet series adopt oil boosting.
  They adopt most up-to-date technology and have many optimized functions, which are not possessed by other China-made oil boosting generators, and also they have higher cutting pressure.

  No. Name Parament Unit
  B2BWJ300 B2BWJ380
  1 Adjusting Range of Cutting Pressure 0-300 0-380 Mpa
  2 Working Pressure 180-250 330-380 Mpa
  3 Maximum Water Flux 2 3.7 L/min
  4 Water Nozzle(Stone)Diameter ?0.25-?0.3 mm
  5 Inner Hole Size of Sand-Mixed Pipe ?0.8 or ?1.0 mm
  6 Maainframe Motor Type Y225S-8 Y225-4
  Rating Power 18.5 37 Kw
  Rating Rotating Speed 726 1480 r/min

  No. Name Parament Unit
  1 Type
  4.0×2.0 4.0×1.5 3.0×2.0 3.0×1.5 2.5×1.5 2.0×1.5 1.6×1.5 1.2×1.0
  2 Maximum Cutting Range
  4000×2000
  4000×1500
  3000×2000
  3000×1500
  2500×1500
  2000×1500
  1600×1500
  1200×1000mm
  3 Travel of Knife Rest 0-200 mm
  4 Driving Speed Servo Motor 0-12000 mm/min
  5 Cutting Accuracy ±0.20 mm
  6 Controlling accurecy ±0.01 mm
  7 Working Motor Servo Motor
  8 Air Compressor Pressure 0.6-0.8 MPa
  9 Abrasive Garnet
  10 abrasive granularity 60-100 Item
  11 Microcomputer 686
  12 Program Software B2B Waterjet Scanning Program System
